Semi-Automatic 18650 Lithium Battery Spot Welder Multi-Pulse Welding Power Supply

Semi-Automatic 18650 Lithium Battery Spot Welder Multi-Pulse Welding Power Supply

  • High Light

    18650 Lithium Battery Spot Welder

    ,

    spot welder for 18650 lithium batteries

  • Product Name
    Pneumatic Lithium Battery Spot Welder
  • Max. Welding Thickness
    0.04-0.2mm
  • Driving Mode
    Pneumatic
  • Warranty Of Core Components
    1 Year
  • Voltage
    220v,Single Phase 50/60Hz
  • Condition
    New
  • After-sales Service Provided
    Online Support
  • Place of Origin
    Guangdong, China
  • Brand Name
    CHEEBO Technology
  • Certification
    CE certification
  • Model Number
    CBLQ-5A
  • Minimum Order Quantity
    1 set
  • Price
    NEGOTIABLE
  • Packaging Details
    Marine moisture-proof wooden case
  • Delivery Time
    5-8 work days
  • Payment Terms
    L/C, D/A, D/P, T/T, Western Union, MoneyGram
  • Supply Ability
    50 Set/Sets per Week

Semi-Automatic 18650 Lithium Battery Spot Welder Multi-Pulse Welding Power Supply

Semi-Automatic 18650 Lithium Battery Spot Welder Multi-Pulse Welding Power Supply




Application scope of the product



Power lithium-ion battery module, 3C lithium-ion battery pack, nickel-metal hydride battery pack, hardware small parts, electronic and electrical



parts, wire terminals, stainless steel parts, metal jewelry, copper products, aluminum products, etc. At the same time, it is also suitable for product



maintenance proofing and other work.





Equipment introduction



1) Using air source solenoid valve signal control


2) Configurable semi linkage function


3) The height of the equipment welding head can be adjusted up and down, and the minimum height of the battery should not be less than 50MM, and the maximum height should not exceed 220MM (the height of the higher version is 300MM). All within this range can be welded.


4) The detachable design of the welding head clamp can be used for both convex spot welding and pointed needle spot welding.


5) High quality tempered glass is used to protect the desktop from wear and tear, making it easy to move during welding.


6) Independently developed precision welding machine head, with precise and adjustable welding pressure and buffer adjustment pressure mechanism, can effectively reduce damage to battery cells during welding.


7) The power supply can store welding parameters internally, with a total of 10 sets of welding parameters. It can weld nickel sheets of different thicknesses and can be easily accessed, making it simple and convenient.


8) By adopting dual stage multi pulse regulation, the welding output energy waveform can be improved, the welding ability can be enhanced, and the welding points can be firm and beautiful. Low power failure rate and high spot welding efficiency


9) The power supply is equipped with automatic monitoring and tracking compensation of grid voltage, which can effectively reduce adverse phenomena such as virtual welding and achieve high-quality welding


10) Using digital LED display, the interface is simple and easy to adjust. The various parameters of the device are more intuitive, easy to learn and operate.


11) The welding power supply adopts a design of post discharge electrodes and can be assembled on automated welding equipment.


12) Adopting industrial grade circuit design, the circuit is safe, reliable, and has a low failure rate.


13) The appearance of the equipment is exquisite, with superior structural design, compact and reasonable structure, small size, and high power.


14) The whole machine adopts high-quality components



Technical specification



Welding thickness 0.02-0.5MM Welding power supply Transistor
Welding mode Single side double point horizontal welding Table top and weld head height 250 (Maximum pitch adjustable)
Supply current 5000A/8000A/10000A Welding speed 200P/M
Spot welding method Bump welding/tip welding Welding pressure 5KG/F
Maximum voltage 30V(Adjustable by oneself) Equipment size 600*900*1300MM
Driving mode Pneumatic Machine Weight 60KG
Power source specification Single-phase 220V50/60HZ Application scenarios Battery welding



Function Introduction



 1. Thickened tempered glass
High quality explosion-proof glass is used to effectively prevent the damage caused to the desktop during welding. At the same time, it can increase the fluency of welding and increase the welding efficiency.



Semi-Automatic 18650 Lithium Battery Spot Welder Multi-Pulse Welding Power Supply 0



 2. Cylinder drive

The air source interface is connected to the pressure regulator to adjust the air source pressure and filter the water. The gas is sent to the solenoid valve, which controls the gas drive cylinder and drives the welding head.



Semi-Automatic 18650 Lithium Battery Spot Welder Multi-Pulse Welding Power Supply 1



 3. Pneumatic precision welding head

Horizontal welding structure, double linear guide design, left and right pressure can be adjusted separately. Built-in pressure sensor, precise control to apply stable pressure.

Semi-Automatic 18650 Lithium Battery Spot Welder Multi-Pulse Welding Power Supply 2



Welding samples

Semi-Automatic 18650 Lithium Battery Spot Welder Multi-Pulse Welding Power Supply 3

FAQ

Q: I don't know which one is right for me?

A: Please tell us the following information

1) Battery model and type.

2) Welding material and welding thickness

3) Commercial industry: We have a lot of sales experience and can provide you with advice.



Q: How do I install and run the machine?

A: Our technicians had installed the machine before shipment. For the installation of some widgets, we will send out detailed training videos and user manuals randomly. 95% of customers can teach themselves.



Q:What's your minimum order quantity?

A: We don't have a minimum order quantity. Whether it is an order of 1 or 100, we will wholeheartedly support you.



Q: How does your factory do in terms of quality control?

A: Quality comes first. More than 20 tests will be performed on each unit. After all the tests are passed, our QC will test the welding performance.



Q :How can I do if the machine goes wrong?

A: If you encounter such problems, please contact us as soon as possible. Do not try to repair the machine by yourself or others. We will respond as soon as possible within 24 hours to solve your problem.
