Butt Welder Hardware Welding Small Metal Pneumatic Spot Welding Machine

Butt Welder Hardware Welding Small Metal Pneumatic Spot Welding Machine

  • High Light

    Pneumatic Equipment For Lithium Battery Assembly

    ,

    Small Equipment For Lithium Battery Assembly

    ,

    Small 18650 Welding Machine

  • Welding Material
    Iron/stainless Steel/nickel/copper
  • Max. Welding Thickness
    1mm
  • Product Name
    Resistance Butt Welding Machine
  • Power Output Mode
    AC
  • Equipment Weight
    25KG
  • Height Of Welding Head
    Adjustable
  • Place of Origin
    Guangdong, China
  • Brand Name
    CHEEBO Technology
  • Certification
    CE certification
  • Model Number
    CBXDH-300
  • Minimum Order Quantity
    1 set
  • Price
    NEGOTIABLE
  • Packaging Details
    Marine moisture-proof wooden case
  • Delivery Time
    5-8 work days
  • Payment Terms
    L/C, D/A, D/P, T/T, Western Union, MoneyGram
  • Supply Ability
    50 Set/Sets per Week

Butt Welder Hardware Welding Small Metal Pneumatic Spot Welding Machine

Butt Welder Hardware Welding Small Metal Pneumatic Spot Welding Machine


Equipment introduction



● Suitable for welding small hardware parts, electronic and electrical parts, wire terminals, stainless steel parts, metal jewelry, copper products, aluminum products, etc. It is also suitable for product maintenance and sampling.


● Single pulse, multi pulse, and dual pulse welding can be achieved through microcontroller control.


● Adopting a proprietary output energy optimization algorithm, the conversion of output voltage and output current is reasonable, with strong welding ability, firm welding joints, no welding errors, low ignition, and excellent surface quality.


● Cheebo's independently developed pneumatic precision welding head ensures precise adjustment and control of pressure.


● Independent welding needle, spring buffering design, precise adjustment of welding pressure.


● The welding head platform can be adjusted up and down, and can weld various batteries.


● Imported high-quality aluminum oxide copper electrodes, pure copper welding cables, pure copper electrode clamps and other accessories make the machine durable and durable.


● Intelligent chip precision control, imported control chip, microsecond level corresponding chip integration process, small size, can work for a long time, and runs stably.


● All parameters are digitally set, and parameter adjustments are stable, intuitive, and accurate.


● Vertical spot welding is adopted, and the welding head pressing depth can be adjusted.


● Digital LED display, device parameter adjustment is more intuitive, easy to learn and operate.


● Microcomputer technology control, power grid voltage control, automatic tracking compensation.


● The portable spot welding machine adopts an integrated design, which saves space and is easy to carry.


● The welding machine can store multiple programs and can be freely modified and called.


● Compact structure, small size, high power, large industrial circuit design, safe and reliable welding process.



Scope of application



1. Wire terminal       2. Metal sheet welding        3. Hardware welding        4. Metal jewelry welding



Butt Welder Hardware Welding Small Metal Pneumatic Spot Welding Machine 0           Butt Welder Hardware Welding Small Metal Pneumatic Spot Welding Machine 1                Butt Welder Hardware Welding Small Metal Pneumatic Spot Welding Machine 2                   Butt Welder Hardware Welding Small Metal Pneumatic Spot Welding Machine 3



Technical specification



Welding thickness 0.04-0.2MM Welding power supply Multiple-pulse
Welding material Metallic Welding needle Optional as required
Supply current 3600A Welding speed 200P/M
Spot welding method Dutt welding Welding pressure 5KG/F
Equipment power 3KW/7KW/12KW Equipment size 560MM*170MM*330MM
Driving mode Pneumatic Machine Weight 20KG
Power source specification Single-phase 220V50/60HZ Application scenarios Battery welding



Debugging project
  1.  Welding pressure: 1-10 kg
  2.  Welding energy adjustment: "+" to increase energy, "-" to reduce energy, "#" to switch parameters
  3.  Air pressure regulation
  4.  Adjustment of needle extension length
  5.  Adjust the lower position of the welding head
  6.  Adjust the spacing between the left and right pins
Function Introduction



 1. Quality accessories

Imported aluminum oxide copper electrode, pure copper welding cable, pure copper electrode clamp, etc., the machine is durable.



Butt Welder Hardware Welding Small Metal Pneumatic Spot Welding Machine 4



 2. Pneumatic precision welding head

Horizontal welding structure, double linear guide design, left and right pressure can be adjusted separately. Built-in pressure sensor, precise control to apply stable pressure.



Butt Welder Hardware Welding Small Metal Pneumatic Spot Welding Machine 5



 3. Operation panel

LED digital display. "+", "-" to adjust the data. "#" switch to adjust the data. Data adjustment is simple and convenient. One-click switch button.



Butt Welder Hardware Welding Small Metal Pneumatic Spot Welding Machine 6



Announcements
  1.  Polish the welding needle regularly.
  2.  Regularly check whether there is loosening in each part.
  3.  Do not disassemble circuit components without permission.
  4.  Periodically clean welding dust from all parts of the device.
  5.  Check the lubrication degree of each moving part every month
  6.  Please read the instructions carefully before operation and operate according to the specifications of the instructions.
