Battery Tab Spot Welding Machine 18650 21700 Cylindrical Battery Pack Assembly

Battery Tab Spot Welding Machine 18650 21700 Cylindrical Battery Pack Assembly

  • Use
    Lithium Battery Assembly
  • Welding Method
    Resistance Welding
  • Welding Current
    AC
  • Frame Material
    Stainless Steel
  • Cable Length
    800MM
  • Product Name
    Multi-pulse Pneumatic Lithium Battery Spot Welding Machine
  • Place of Origin
    Guangdong, China
  • Brand Name
    CHEEBO Technology
  • Certification
    CE certification
  • Model Number
    CBLQ-26
  • Minimum Order Quantity
    1 set
  • Price
    NEGOTIABLE
  • Packaging Details
    Marine moisture-proof wooden case
  • Payment Terms
    L/C, D/A, D/P, T/T, Western Union, MoneyGram
  • Supply Ability
    50 Set/Sets per Week

Battery Tab Spot Welding Machine 18650 21700 Cylindrical Battery Pack Assembly

Battery Tab Spot Welding Machine 18650 21700 Cylindrical Battery Pack Assembly


Equipment introduction



● Application fields: power lithium ion battery pack welding, 3C lithium ion battery pack welding, Ni-MH battery pack welding, small hardware welding, electronic device welding, wire terminal welding, stainless steel parts welding, metal jewelry welding, copper products welding, aluminum products welding and so on.


● It is also suitable for product maintenance, proofing and other welding work.


● Digital LED display, more intuitive adjustment of equipment parameters, easy to learn and operate.


● The self-developed precision welding head has accurate pressure adjustment control.


● Proprietary output energy optimization algorithm, reasonable output voltage and current conversion, strong welding ability, firm and clear welding joint, no false welding and stir-frying welding.


● The cremation is small during welding and the surface quality is good.


● Microcomputer technology control, control grid voltage, automatic tracking compensation.


● Applicable battery size: the minimum is not less than 50MM, the maximum is not greater than 130MM.


● The use of high-quality tempered glass to protect the Mesa from wear during welding.


● Spot welding adopts vertical spot welding, and the depth of pressing is controlled manually.


● The welding machine can store a number of programs, which can be changed and called at will.


● Compact structure, small size, high power, large industrial circuit design, safe and reliable welding process



Technical specification



Welding thickness 0.02-0.18MM Welding power supply Multiple-pulse
Welding mode Single side double point horizontal welding Table top and weld head height 130MM (Maximum pitch adjustable)
Supply current 3000A Welding speed 200P/M
Spot welding method Bump welding/tip welding Welding pressure 5KG/F
Equipment power 12KW Equipment size 600*900*1300MM
Driving mode Pneumatic Machine Weight 60KG
Power source specification Single-phase 220V50/60HZ Application scenarios Battery welding



Device action flow description



Power on - display 600 OE self-test screen - press the up arrow to enter the system - place the product to be soldered on the desktop -



press the foot pedal - press the soldering head down - spot soldering is complete - the soldering head is back in place



  1. Welding case



Battery Tab Spot Welding Machine 18650 21700 Cylindrical Battery Pack Assembly 0        Battery Tab Spot Welding Machine 18650 21700 Cylindrical Battery Pack Assembly 1       Battery Tab Spot Welding Machine 18650 21700 Cylindrical Battery Pack Assembly 2



Function Introduction



 1. Cylinder drive

The air source interface is connected to the pressure regulator to adjust the air source pressure and filter the water. The gas is sent to the solenoid valve, which controls the gas drive cylinder and drives the welding head.



Battery Tab Spot Welding Machine 18650 21700 Cylindrical Battery Pack Assembly 3



 2. Adjusting mechanism of welding head

The welding head can be adjusted up and down to increase the distance between the desktop and the welding head. Can weld a variety of different heights, different types of cells.



Battery Tab Spot Welding Machine 18650 21700 Cylindrical Battery Pack Assembly 4



 3. Adjusting mechanism of welding head

The welding head can be adjusted up and down to increase the distance between the desktop and the welding head. Can weld a variety of different heights, different types of cells.



Battery Tab Spot Welding Machine 18650 21700 Cylindrical Battery Pack Assembly 4



FAQ



Q: I don't know which one is right for me?

A: Please tell us the following information

1) Battery model and type.

2) Welding material and welding thickness

3) Commercial industry: We have a lot of sales experience and can provide you with advice.



Q: How do I install and run the machine?

A: Our technicians had installed the machine before shipment. For the installation of some widgets, we will send out detailed training videos and user manuals randomly. 95% of customers can teach themselves.



Q: What's your minimum order quantity?

A: We don't have a minimum order quantity. Whether it is an order of 1 or 100, we will wholeheartedly support you.



Q: How does your factory do in terms of quality control?

A: Quality comes first. More than 20 tests will be performed on each unit. After all the tests are passed, our QC will test the welding performance.



Q: How can I do if the machine goes wrong?

A: If you encounter such problems, please contact us as soon as possible. Do not try to repair the machine by yourself or others. We will respond as soon as possible within 24 hours to solve your problem.



Looking forward to your consultation, we will provide you with the best quality service throughout the process!!!
