High Efficiency Weld 18650 Pneumatic Battery Tab Spot Welding Machine

Brand Name:	CHEEBO Technology
Model Number:	CBLQ-26
MOQ:	1 set
Price:	NEGOTIABLE
Packaging Details:	Marine moisture-proof wooden case
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Certification:

CE certification

Voltage:

Warranty:

1 Year

Key Selling Points:

Easy To Operate

Product Name:

Multi-pulse Pneumatic Lithium Battery Spot Welding Machine

Weight (KG):

60 KG

After-sales Service Provided:

Online Service Provided

Supply Ability:

50 Set/Sets per Week

Highlight:

High Efficiency Lithium Spot Welder

Pneumatic Lithium Spot Welder

Pneumatic Spot Welding Accessories

Product Description

High Efficiency Weld 18650 Pneumatic Battery Tab Spot Welding Machine

Equipment introduction

● Product application: power lithium-ion battery module welding, 3C lithium-ion battery pack welding, nickel-metal hydride battery pack welding, hardware accessories welding, electronic and electrical accessories welding, wire terminal welding, stainless steel accessories welding, metal jewelry welding, copper products welding, aluminum products welding, etc.

● Digital LED display, device parameter adjustment is more intuitive, easy to learn and operate.

● Self-developed precision welding head, accurate pressure regulation control.

● Proprietary output energy optimization algorithm, reasonable output voltage and output current transformation, strong welding ability, solid solder joint, no virtual welding, small cremation, good surface quality.

● Microcomputer technology control, control grid voltage, automatic tracking compensation.

● Applicable battery specifications: minimum no less than 50MM, maximum no more than 130MM. (Over can be used to increase height)

● High quality tempered glass is used to protect the table top from wear during welding.

● Vertical spot welding, manual control of the depth of pressure.

● The welder can store multiple programs in advance, and these programs can be changed and called at will.

● Compact structure, small size, large power, large industrial circuit design, safe and reliable welding process.

High Efficiency Weld 18650 Pneumatic Battery Tab Spot Welding Machine 0

Function Introduction

1. Adjusting mechanism of welding head

The welding head can be adjusted up and down to increase the distance between the desktop and the welding head. Can weld a variety of different heights, different types of cells.

High Efficiency Weld 18650 Pneumatic Battery Tab Spot Welding Machine 1

2. Multi-pulse welding power supply

Proprietary output energy optimization algorithm, output voltage and output current transformation is reasonable, strong welding ability, solid solder joint, no virtual welding, small cremation, excellent surface quality.

High Efficiency Weld 18650 Pneumatic Battery Tab Spot Welding Machine 2

3. Cylinder drive

The air source interface is connected to the pressure regulator to adjust the air source pressure and filter the water. The gas is sent to the solenoid valve, which controls the gas drive cylinder and drives the welding head.

High Efficiency Weld 18650 Pneumatic Battery Tab Spot Welding Machine 3

Technical specification

Welding thickness	0.02-0.18MM	Welding power supply	Multiple-pulse
Welding mode	Single side double point horizontal welding	Table top and weld head height	130MM (Maximum pitch adjustable)
Supply current	3000A	Welding speed	200P/M
Spot welding method	Bump welding/tip welding	Welding pressure	5KG/F
Equipment power	12KW	Equipment size	6009001300MM
Driving mode	Pneumatic	Machine Weight	60KG
Power source specification	Single-phase 220V50/60HZ	Application scenarios	Battery welding

Welding case

High Efficiency Weld 18650 Pneumatic Battery Tab Spot Welding Machine 4

FAQ

Q: What's your minimum order quantity?

A: We don't have a minimum order quantity. Whether it is an order of 1 or 100, we will wholeheartedly support you.

Q: How do I install and run the machine?

A: Our technicians had installed the machine before shipment. For the installation of some widgets, we will send out detailed training videos and user manuals randomly. 95% of customers can teach themselves.

Q: I don't know which one is right for me?

A: Please tell us the following information

1) Battery model and type.

2) Welding material and welding thickness

3) Commercial industry: We have a lot of sales experience and can provide you with advice.

Q: How does your factory do in terms of quality control?

A: Quality comes first. More than 20 tests will be performed on each unit. After all the tests are passed, our QC will test the welding performance.

Q: How can I do if the machine goes wrong?

A: If you encounter such problems, please contact us as soon as possible. Do not try to repair the machine by yourself or others. We will respond as soon as possible within 24 hours to solve your problem.

High Efficiency Weld 18650 Pneumatic Battery Tab Spot Welding Machine 7

Service process
Pre-sale:
1. Customers send inquiries and inquiries
2. Recommend products according to customer needs
3. Video communication to confirm final requirements
4. Both parties shall deliver the confirmation of technical specifications
5. Both parties sign the contract
6. Place orders and arrange production in the workshop
7. Arrange delivery
After sale:
1. Confirm whether customers need on-site service or video communication guidance for debugging equipment.
2. If there is any problem with the equipment, video communication will be adopted to solve the problem first. Door-to-door service can be provided if there is no solution.

Looking forward to your consultation, we will provide you with the best quality service throughout the process!!!
