    Multi-function Single Side Double Station Spot Welding Machine
  • Dimensions
    600*900*1420
  • Power Supply
    220V50/60HZ 2.8KW
  • Station Rotation Angle
    180°
  • Welding Head Rotation Angle
    135° (Max.)
  • Place of Origin
    Guangdong, China
  • Brand Name
    CHEEBO Technology
  • Certification
    CE certification
  • Model Number
    CBMO4-1710
  • Minimum Order Quantity
    1 set
  • Price
    NEGOTIABLE
  • Packaging Details
    Marine moisture-proof wooden case
  • Payment Terms
    L/C, D/A, D/P, T/T, Western Union, MoneyGram
  • Supply Ability
    10 Set/Sets per Week

Cylindrical Cell Welding Automatic Battery Spot Welding Machine Transistor Supply

Cylindrical Cell Welding Automatic Battery Spot Welding Machine Transistor Supply


Equipment introduction



● With energy switching function, production counting function, weld pin compensation function, manual debugging function, etc. It can assist the intelligent operation of the equipment.


● Energy switching function can store 4 groups of energy modes and automatically switch different welding energy for different materials.


● Production count function, set the production quantity, and automatically stop the welding pin compensation function when the production is completed.


● Manual debugging function, you can fine tune the welding head for each point and save the spot welding parameters (for easy modification of the coordinates of the welding point), or use the one-touch correction function for adjustment.


● The welding fixture is designed to automatically flip to the B-side after the A-side welding is completed, eliminating the need to manually flip the fixture.


● The welding head can be rotated 135°, which is suitable for welding irregularly shaped nickel sheets and effectively avoiding needle staining during the welding process.


● Grid protection device is installed on both sides to ensure safe operation of the equipment.


● Fry welding and false welding equipment will automatically alarm, automatic area fill welding, single point fill welding manual adjustment.


● Adopting HIWIN module, high precision, low noise, smooth sliding and durable.


● Adopt Panasonic servo, fast welding speed and high precision.


● High-definition LCD touch screen, human-machine interaction interface, easy and convenient operation.


● Independent development of various automatic intelligent systems to facilitate equipment operation and help improve production efficiency.


● Manual programming, CAD drawing, import of spot welding paths, and fast programming. Easy to learn and fully competent for production line workers.


● Aluminum alloy structure, electrostatic powder coating process, anti-scratch, anti-rust and anti-static.


● Imported acrylic protection plate, beautiful and elegant, strong sense of technology, intuitive operation, improve production safety factor.



Technical specification
Comprehensive time limit
3200PCS/H
Equipment weight
350KG
Weld thickness
0.3mm(More than 0.2 nickel pieces need to be slotted and dotted)
Device power
220V50/60HZ
Equipment power
2KW (including power supply)
Equipment travel
170*100 (mm) about 45 18650 cells(One work station)
Power consumption
0.8KW in busy time, 0.2KW in idle time
Way of exercise
automatic continuous
Electrode material
Alumina copper
Cooling method
Forced water circulation cooling
Dimensions
1000*1200*1750(mm)
Application scenarios
Mass welding of cylindrical batteries, welding of special-shaped nickel sheets for power tools



Function Introduction



 1. Transistor welding power supply

Welding energy output is the most stable power supply, real-time display of welding voltage and current waveform, current rising fast, can achieve high quality welding in a short time.



Cylindrical Cell Welding Automatic Battery Spot Welding Machine Transistor Supply 0

 3. Double station rotating platform

The fixture automatic rotating mechanism is adopted. After the welding of side A, it automatically rotates to welding of side B without manual turnover. Provide productivity.



Cylindrical Cell Welding Automatic Battery Spot Welding Machine Transistor Supply 1



 3. Precision servo welding head

The welding head can be rotated 135°. Suitable for all kinds of shaped nickel sheet, effectively prevent sticking needle and other bad welding phenomenon, welding head pressure can be adjusted.



Cylindrical Cell Welding Automatic Battery Spot Welding Machine Transistor Supply 2
