DC Mode Automatic Battery Spot Welding Machine 18650 With Double Station
● This lithium battery spot welding machine is a multi-axis control machine tool developed by modern automation experts, equipped with precision transmission and motor control mechanism, self-propelled travelling mechanism, automated production equipment, effective real-time control of processing.
● Applicable to fully automatic single-side spot welding of 18650, 21700, 26650, 32700 and other cylindrical battery combinations.
● CBMO4-1710 Li-ion battery welding single-side machine adopts welding fixture design, which can be automatically turned over after A-side welding is completed, and can be automatically turned over to B-side welding without manually turning over the fixture.
● CHEEBO core welding head automatic spot welder can be rotated 135°, which is suitable for the welding of irregular shape nickel sheet, and effectively avoid the needle dirt during welding.
● There are grid protection devices on both sides to ensure the safe operation of the equipment.
● Blow-up welding and false welding equipment will automatically alarm, automatic area replenishment welding, single-point replenishment welding manual adjustment.
● Adopt HIWIN module, high precision, low noise, smooth and durable sliding.
● Adopt Panasonic servo, fast welding speed and high precision.
● High-definition LCD touch screen, human-machine interactive interface, easy and convenient operation.
● Independently developed various automation intelligent system, convenient for equipment operation, help to improve production efficiency.
● With energy switching function, production counting function, soldering foot compensation function, manual debugging function and so on. It can assist the intelligent operation of equipment.
● Manual programming, CAD drawing, spot welding path import, quick programming. Easy to learn, fully competent for production line workers.
● Aluminium alloy structure, electrostatic powder coating process, scratch-resistant, anti-rust, anti-static.
● Imported acrylic protection plate, beautiful and elegant, strong sense of technology, intuitive operation, improve production safety factor.
|
Comprehensive time limit
|
3200PCS/H
|
|
Equipment weight
|
350KG
|
|
Weld thickness
|
0.3mm(More than 0.2 nickel pieces need to be slotted and dotted)
|
|
Device power
|
220V50/60HZ
|
|
Equipment power
|
2KW (including power supply)
|
|
Equipment travel
|
170*100 (mm) about 45 18650 cells(One work station)
|
|
Power consumption
|
0.8KW in busy time, 0.2KW in idle time
|
|
Way of exercise
|
automatic continuous
|
|
Electrode material
|
Alumina copper
|
|
Cooling method
|
Forced water circulation cooling
|
|
Dimensions
|
1000*1200*1750(mm)
|
|
Application scenarios
|
Mass welding of cylindrical batteries, welding of special-shaped nickel sheets for power tools
|
1. Transistor welding power supply
Welding energy output is the most stable power supply, real-time display of welding voltage and current waveform, current rising fast, can achieve high quality welding in a short time.
2. Precision servo welding head
The welding head can be rotated 135°. Suitable for all kinds of shaped nickel sheet, effectively prevent sticking needle and other bad welding phenomenon, welding head pressure can be adjusted.
3. Hd touch screen
Real-time display of welding data, welding hole location. System parameter setting is simple and easy to learn.
Support manual programming, CCD mapping, import solder joint path to achieve fast programming.
