● Cell automatic feeding mechanism: the mechanical arm automatically grabs the cell and is placed on the specified track. It is 18-21 in diameter and 65-70 in length.

● Electric core highland barley paper machine: The stepper motor and cylinder controlled by PLC are used to paste the highland barley paper on the positive electrode of the finished electric core. Using a cylinder driven cutter, stamping and pasting four cells at a time. The sections are made of high speed steel with high wear resistance.

● Battery sorting machine: It has the function of scanning and data storage for the battery. 7 sorting gears. Automatic sorting equipment suitable for various specifications of cylindrical battery voltage and internal resistance test. It is 18-21 in diameter and 65-70 in length.

● CCD vision inspection equipment: multi-functional vision inspection system based on CCD industrial camera and machine vision technology.

● Battery automatic spot welding machine: suitable for welding various specifications of cylindrical batteries, using automatic single-side spot welding welding.

● Fixture rotation system: automatically sensing the fixture to reach its position, rotating mechanism clamping fixture rotation, so that the fixture return to the next program.

● The lithium battery pack production line is suitable for the battery pack assembly production of household appliances/electric bicycles/power tools/garden tools/energy storage power supplies and other products.

● Modular design: each device can be automatically connected or used separately, and can be freely combined and used on demand.

● Lithium battery production line is a multi-axis motion control system developed by modern automation experts. Automatic mechanism with precision drive and motor control for real-time and effective control of automated production equipment.

● Lithium battery assembly line is suitable for 18650, 21700, 26650, 32700 and other cylindrical battery assembly lines.

● The built-in fixture is returned to the track, after the assembly is completed, the fixture is manually removed and placed on the return track. The fixture is automatically returned to the previous station, and the welding track is placed after manual assembly.

The battery is loaded into the hopper of the paper paste machine →→ Automatically paste the positive electrode

pad sticker →→ the battery automatically enters the separator →→ the separator sweeps the test data for archiving →→

The battery is sent into the corresponding receiving tank → The workers take out the loading fixture in groups →

push the CCD automatic polarity detection screen → the unqualified manual correction is automatically sent out →

the workers cover the upper plate of the fixture →→ push the spot welder Automatic spot welding on side A→→

The machine automatically turns over to side B for welding completion →→ Take out the welded battery pack fixture

and return it to the frontto enter the next escape ring →→ Install the BMS board after the battery pack welding

inspection →→Machine or manual welding of the BMS board → Workers line and install auxiliary materials →→

Test the battery pack parameters fail to pass the inspection. →→ Send aging inspection to aging workshop →→

Packaging workshop packing

1. Battery automatic feeding

2. Positive electrode paste insulated paper machine

3. Cell voltage internal resistance sorting

4. Cell mounting bracket fixture platform

5. CCD detection of positive and negative battery pack

6. Fixture cover top plate platform

7. Spot welding on side A

8. Fixture turning mechanism

9. Side B welding

10. Back-end installation production line
