The gantry structure can achieve large-scale welding and supports the installation of multiple fixtures simultaneously for welding various specifications and models of lithium-ion battery packs. The galvanometer system is used to accurately adjust the direction and position of the laser beam, achieving high-precision control of the welding area and improving welding quality.
1. The continuous galvanometer laser welding machine adopts the most advanced fiber laser as the laser source, designed specifically for high reflective materials (aluminum). Combined with our company's independently developed and designed gantry machine tool, it has good rigidity and stability. For fast and precise welding, fiber lasers have a series of advantages such as high beam quality, stability and reliability, low operating costs, and small size, making them the preferred equipment for lithium-ion laser welding processing.
3. High lifespan gantry dual drive motion platform cabinet, gantry style motion structure, large surface welding range, high photoelectric conversion efficiency, and excellent beam quality.
4. Adopting precision guide rail transmission, equipped with high response servo motor, high precision and fast speed;
5. Laser welding has small welding points, high melting depth, small taper, high precision, and smooth welding surface without bubbles; Laser welding processing is pollution-free, with a small heat affected area and minimal deformation;
6. PC industrial computer, welding CNC programming system, welding software editing is simple and easy to learn.
7. The laser power is adjustable, with low power consumption and no need for daily maintenance. The automatic top pressure welding device reduces the requirements for welding fixture 9. Support adding CCD visual positioning system and automatic focal length measurement system functions
8. The automatic top pressure welding device reduces the requirements for welding fixtures
9. Support adding CCD visual positioning system and automatic focal length measurement system functions
TECHNICIAL PARAMETERS
|
|||
Laser Power
|
1500W/2000W/3000W/4000W/6000W
|
||
Fiber core
|
20um/50pm/100pm(Optional)
|
||
The Laser Wavelength
|
1.06um
|
||
Operation Model
|
Continuous/Modulation
|
||
Laser Welding Depth (stainless steel)
|
1mm~4.0mm
|
||
Positioning System (GPS)
|
Red light indication
|
||
Power Demand
|
220V 50HZ/60HZ , 380V/50HZ/60HZ
|
||
Cooling Mode
|
Water Cooling
|
||
The Whole Machine Consumes Power
|
<3KW
|
||
Brand name
|
cheebo
|
||
Warranty
|
1 Year
|
||
The Whole Machine Size
|
WLH (1500*1700*2500mm)
|
1. Precise positioning
Optical fiber laser welding machine is equipped with CCD camera monitoring system, which is convenient to observe, and can precisely locate by spot in micro-welding.
2. Uniform weld spot
The spot energy distribution of optical fiber laser welding machine is uniform, and it has the best spot needed for welding characteristics.
3. Suitable for all kinds of weld's screams
Fiber laser welding machine adapts to all kinds of complex welds, spot welding of various devices, and welding seams of thin plates within 1mm. It has fast welding speed, large depth and small deformation.
Q: I don't know which one suits me?
A: Please provide us with the following information
1) Battery model and type.
2) Welding materials and welding thickness
3) Business industry: We have extensive sales experience and can provide you with advice.
Q: How to install and operate the machine?
A: Our technicians installed the machine before shipment. For the installation of some small components, we will randomly send detailed training videos and user manuals. 95% of customers can self-study.
Q: What is your minimum order quantity?
A: We do not have a minimum order quantity. Whether it's Order 1 or Order 100, we will wholeheartedly support you.
Q: How is your factory doing in terms of quality control?
A: Quality comes first. Each unit will undergo over 20 tests. After all tests pass, our quality control personnel will test the welding performance.
Q: What should I do if the machine has a problem?
A: If you encounter such problems, please contact us as soon as possible. Do not attempt to repair the machine yourself or others. We will reply as soon as possible within 24 hours to resolve your issue.
